Item
Name: |
Directional
Panel Antenna |
Beamwidth
H: |
30/45°
±6° |
|
Model: |
PA-727-12DBN/OD |
Beamwidth V: |
45/60°
±6° |
|
Class: |
Directional
Panel |
Polarization: |
Vertical |
|
Frequency: |
698-960,1710-2700MHz |
Impedance: |
50 Ω
, N/F |
|
|
|
|
|
|
|
|
|
|
|
Power: |
50W |
Size: |
256X170X56mm |
|
Gain: |
11/12 dB |
Weight: |
0.50kg |
|
VSWR: |
< 1.6 |
Remark: |
Aluminum
Plate |
|
|
|
|
|
Item
Name: |
Directional
Panel Antenna |
Beamwidth
H: |
68°
±10° |
|
Model: |
PA-825-8DBN/OD |
Beamwidth V: |
58°
±10° |
|
Class: |
Directional
Panel |
Polarization: |
Vertical |
|
Frequency: |
806-960,1710-2500MHz |
Impedance: |
50 Ω
, N/F |
|
Power: |
50W |
Size: |
210X180X45mm |
|
Gain: |
8 dB |
Weight: |
0.75kg |
|
VSWR: |
< 1.5 |
Remark: |
Aluminum
Plate |
|
|
|
|
|
Item
Name: |
Directional
Panel Antenna |
Beamwidth
H: |
68°
±10° |
|
Model: |
PA-825-8DBNH/OD |
Beamwidth V: |
58°
±10° |
|
Class: |
Directional
Panel |
Polarization: |
Vertical |
|
Frequency: |
806-960,1710-2500MHz |
Impedance: |
50 Ω
, N/F |
|
Power: |
50W |
Size: |
210X180X45mm |
|
Gain: |
8 dB |
Weight: |
0.75kg |
|
VSWR: |
< 1.5
(PIM< -140dBc)
|
Remark: |
Aluminum
Plate |
|
|
|
|
|
Item
Name: |
Directional
Panel Antenna |
Beamwidth
H: |
75~115°
±10° |
|
Model: |
PA-727-8DBNE/OD |
Beamwidth V: |
58°
±10° |
|
Class: |
Directional
Panel |
Polarization: |
Vertical |
|
Frequency: |
698-960,1710-2700MHz |
Impedance: |
50 Ω
, N/F |
|
Power: |
50W |
Size: |
210X180X45mm |
|
Gain: |
8 dB |
Weight: |
0.75kg |
|
VSWR: |
< 1.5 |
Remark: |
Aluminum
Plate |
|
|
|
|
|
Item
Name: |
Directional
Panel Antenna |
Beamwidth
H: |
75~115°
±10° |
|
Model: |
PA-727-8DBNH/OD |
Beamwidth V: |
58°
±10° |
|
Class: |
Directional
Panel |
Polarization: |
Vertical |
|
Frequency: |
698-960,1710-2700MHz |
Impedance: |
50 Ω
, N/F |
|
Power: |
50W |
Size: |
210X180X45mm |
|
Gain: |
8 dB |
Weight: |
0.75kg |
|
VSWR: |
< 1.5
(PIM< -140dBc)
|
Remark: |
Aluminum
Plate |
|
|
|
|
|
