PRODUCT >> Gas Discharge SERIES SURGE PROTECTOR(SURGE ARRESTER)

 Item Name:  Gas Discharge Protector  Insertion loss:   0.30
 Model:  BLQ-GDI-6G43MD/MF  V.S.W.R:  ≒ 1.20
 Class:  Gas Discharge Inside  Impedance:  50 次
 Frequency:  DC-6G  Operating Vtg:  75V
 Peak Power:  500W (MAX)  Connector:  4.3-10-M/F
 Discharge Capacity:  5KA(10KA MAX)  Temperature:  -40- +70
 Item Name:  Gas Discharge Protector  Insertion loss:   0.30
 Model:  BLQ-GDI-6G43MD/FF  V.S.W.R:  ≒ 1.20
 Class:  Gas Discharge Inside  Impedance:  50 次
 Frequency:  DC-6G  Operating Vtg:  75V
 Peak Power:  500W (MAX)  Connector:  4.3-10-F/F
 Discharge Capacity:  5KA(10KA MAX)  Temperature:  -40- +70
 Item Name:  Gas Discharge Protector  Insertion loss:   0.30
 Model:  BLQ-GD-3G43MD/MF  V.S.W.R:  ≒ 1.20
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-3G  Operating Vtg:  75V
 Peak Power:  500W (MAX)  Connector:  4.3-10-M/F
 Discharge Capacity:  10KA(20KA MAX)  Temperature:  -40- +70
 Item Name:  Gas Discharge Protector  Insertion loss:   0.30
 Model:  BLQ-GD-3G43MD/FF  V.S.W.R:  ≒ 1.20
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-3G  Operating Vtg:  75V
 Peak Power:  500W (MAX)  Connector:  4.3-10-F/F
 Discharge Capacity:  10KA(20KA MAX)  Temperature:  -40- +70
 Item Name:  Gas Discharge Protector  Insertion loss:   0.25
 Model:  BLQ-GD-3GNSMABR  V.S.W.R:  ≒ 1.15
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-3G  Operating Vtg:  90V/230V
 Peak Power:  200W  Connector:  N/F-SMA/F
 Discharge Capacity:  10KA(20KA MAX)  Temperature:  -40- +70
 Item Name:  Gas Discharge Protector  Insertion loss:   0.10
 Model:  BLQ-GD-3GDBC  V.S.W.R:  ≒ 1.20
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-3000MHz  Bulkhead:  Yes
 Peak Power:  500W (MAX)  Connector:  7/16(DIN)-M/F
 Discharge Capacity:  20KA  Temperature:  -40- +80
 Item Name:  Gas Discharge Protector  Insertion loss:   0.10
 Model:  BLQ-GD-3GDB  V.S.W.R:  ≒ 1.20
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-3000MHz  Bulkhead:  Yes
 Peak Power:  500W (MAX)  Connector:  7/16(DIN)-M/F
 Discharge Capacity:  20KA  Temperature:  -40- +80
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD-3GNBS  V.S.W.R:  ≒ 1.15
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-3000MHz  Bulkhead:  Yes
 Peak Power:  200W (MAX)  Connector:  N-M/F
 Discharge Capacity:  20KA  Temperature:  -40- +85
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD-3GNBD  V.S.W.R:  ≒ 1.15
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-3000MHz  Bulkhead:  Yes
 Peak Power:  200W (MAX)  Connector:  N-F/F
 Discharge Capacity:  20KA  Temperature:  -40- +85
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD/I-3GNBR  V.S.W.R:  ≒ 1.15
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-3000MHz  Bulkhead:  Yes
 Peak Power:  200W (MAX)  Connector:  N-F/F
 Discharge Capacity:  20  Temperature:  -40- +85
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD-3GNBR  V.S.W.R:  ≒ 1.15
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-3000MHz  Bulkhead:  Yes
 Peak Power:  200W (MAX)  Connector:  N-M/F
 Discharge Capacity:  20  Temperature:  -40- +85
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD-6GNBR  V.S.W.R:  ≒ 1.40
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-6000MHz  Bulkhead:  Yes
 Peak Power:  200W (MAX)  Connector:  N-M/F
 Discharge Capacity:  10KA/20KA  Temperature:  -40- +85
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD-6GNFBR  V.S.W.R:  ≒ 1.40
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-6000MHz  Bulkhead:  Yes
 Peak Power:  200W (MAX)  Connector:  N-F/F
 Discharge Capacity:  10KA/20KA  Temperature:  -40- +85
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD-2.5GNBZ  V.S.W.R:  ≒ 1.15
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-2500MHz  Bulkhead:  Yes
 Peak Power:  200W (MAX)  Connector:  N-M/F
 Discharge Capacity:  20KA  Temperature:  -40- +85
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD-2.5GTBC  V.S.W.R:  ≒ 1.15
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-2500MHz  Bulkhead:  Yes
 Peak Power:  200W (MAX)  Connector:  TNC-M/F
 Discharge Capacity:  20KA  Temperature:  -40- +85
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD-3GSBC  V.S.W.R:  ≒ 1.15
 Class:  Gas Discharge  Impedance:  50 次
 Frequency:  DC-2500MHz  Bulkhead:  Yes
 Peak Power:  200W (MAX)  Connector:  SMA-M/F
 Discharge Capacity:  20KA  Temperature:  -40- +85
 Item Name:  Gas Discharge Protector  Insertion loss:   0.20
 Model:  BLQ-GD-2.5GFA  V.S.W.R:  ≒ 1.20
 Class:  Gas Discharge  Impedance:  75 次
 Frequency:  DC-2500MHz  Bulkhead:  Yes
 Peak Power:  200W  Connector:  F-M/F
 Discharge Capacity:  20KA  Temperature:  -40- +80
 Item Name:  Hybrid Quarter Wave  Insertion loss:   0.20
 Model:  BLQ-HGD-722GDB  V.S.W.R:  ≒ 1.20
 Class:  1/4竹+Gas Discharge  Impedance:  50 次
 Frequency:  698-2200MHz  Bulkhead:  Yes
 Discharge Voltage:  90/250/350/600V  Connector:  7/16(DIN)-M/F
 Discharge Capacity:  20KA  Temperature:  -40- +80
 Item Name:  Hybrid Quarter Wave  Insertion loss:   0.20
 Model:  BLQ-HGD-825GDB  V.S.W.R:  ≒ 1.20
 Class:  1/4竹+Gas Discharge  Impedance:  50 次
 Frequency:  800-2500MHz  Bulkhead:  Yes
 Discharge Voltage:  90/350V  Connector:  7/16(DIN)-F/F
 Discharge Capacity:  20KA  Temperature:  -40- +80
 Item Name:  Hybrid Quarter Wave  Insertion loss:   0.20
 Model:  BLQ-HGD-727GD  V.S.W.R:  ≒ 1.20
 Class:  1/4竹+Gas Discharge  Impedance:  50 次
 Frequency:  698-2700MHz  Bulkhead:  Yes
 Discharge Voltage:  350V  Connector:  7/16(DIN)-F/F
 Discharge Capacity:  30KA  Temperature:  -40- +80
 Item Name:  Gas Discharge Tube  →Vdc(%)  ㊣ 20%
 Model:  H2R-VXX  I(KA@8/20米S  5
 Class:  Gas Discharge Tube  I(A@10/1000米S)  100
 Vdc(V@100v/s)  90/150/230/350/600  Cp(pF@1MHz)  ≒ 1.5
